Mybatis-注解sql

Demo

主启动类

public class MybatisHelloWorld {
    public static void main(String[] args) throws Exception {
        String resource = "org/mybatis/config.xml";
        InputStream inputStream = Resources.getResourceAsStream(resource);
        SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);
        SqlSession session = sqlSessionFactory.openSession();
        UserMapper mapper = session.getMapper(UserMapper.class);
        List users = mapper.getUsers(1);
        session.close();
    }
}

userMapper.class

public interface UserMapper {
    @Select({"select * from user where age=#{age}"})
    List getUsers(int age);
}

config.xml


        //控制台输出sql



















Mybatis通过session来进行数据库的操作,sqlSessionFactory封装了session的创建,而SqlSessionFactoryBuilder又封装了sqlSessionFactory的创建

从上面代码来看总共做了两件事

1. 读取配置文件,通过SqlSessionFactoryBuilder创建sqlSessionFactory继而创建session
2. 获取mapper进行读取数据库

先来看如何将xml配置文件封装为对象的

解析配置文件

new SqlSessionFactoryBuilder().build(inputStream);

这里使用构造者模式来创建一个sqlSessionFactory,里面使用重载

public SqlSessionFactory build(InputStream inputStream) {
    return build(inputStream, null, null);
}

最终调用

SqlSessionFactoryBuilder.java

public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
    try {
        //创建一个xml解析类
        XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, environment, properties);
        //解析xml中配置,转换为configuration类
        return build(parser.parse());
    } catch (Exception e) {
        throw ExceptionFactory.wrapException("Error building SqlSession.", e);
    } finally {
        ErrorContext.instance().reset();
        try {
            inputStream.close();
        } catch (IOException e) {
            // Intentionally ignore. Prefer previous error.
        }
    }
}

mybatis是把一些配置类以及它自己需要使用的各种类封装成一个大的config对象

org.apache.ibatis.session.Configuration 里面有很多环境,mapper等等的信息,内容太多就不粘贴了

XMLConfigBuilder.java

public XMLConfigBuilder(InputStream inputStream, String environment, Properties props) {
    this(new XPathParser(inputStream, true, props, new XMLMapperEntityResolver()), environment, props);
}

private XMLConfigBuilder(XPathParser parser, String environment, Properties props) {
    //创建了一个Configuration 对象
    super(new Configuration());
    ErrorContext.instance().resource("SQL Mapper Configuration");
    this.configuration.setVariables(props);
    this.parsed = false;
    //这一行设置环境id
    this.environment = environment;
    this.parser = parser;
}

XMlConfigBuilder类关系图

BaseBuilder.java

 public BaseBuilder(Configuration configuration) {
    this.configuration = configuration;
    this.typeAliasRegistry = this.configuration.getTypeAliasRegistry();
    this.typeHandlerRegistry = this.configuration.getTypeHandlerRegistry();
  }

解析主配置文件.xml

SqlSessionFactoryBuilder.java

public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
    //....
    return build(parser.parse());
    //....
}

public Configuration parse() {
    if (parsed) {
        throw new BuilderException("Each XMLConfigBuilder can only be used once.");
    }
    parsed = true;
    //读取configuration节点下的node传入
    parseConfiguration(parser.evalNode("/configuration"));
    return configuration;
}


private void parseConfiguration(XNode root) {
    try {
        //issue #117 read properties first
        //读取properties
        propertiesElement(root.evalNode("properties"));
        //读取一些setting设置
        Properties settings = settingsAsProperties(root.evalNode("settings"));
        loadCustomVfs(settings);
        //注册别名
        typeAliasesElement(root.evalNode("typeAliases"));
        //插件,进行增强-先略过
        pluginElement(root.evalNode("plugins"));
        //对象工厂,自定义实例化方法--略过
        objectFactoryElement(root.evalNode("objectFactory"));
        objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
        reflectionFactoryElement(root.evalNode("reflectionFactory"));
        settingsElement(settings);
        // read it after objectFactory and objectWrapperFactory issue #631
        //配置环境
        environmentsElement(root.evalNode("environments"));
        //数据厂商表示--略过
        databaseIdProviderElement(root.evalNode("databaseIdProvider"));
        typeHandlerElement(root.evalNode("typeHandlers"));
        //配置mapper
        mapperElement(root.evalNode("mappers"));
    } catch (Exception e) {
        throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
    }
}

解析的东西很多,我们只先看environments和mapper

environmentsElement

XMLConfigBuilder.java

private void environmentsElement(XNode context) throws Exception {
    if (context != null) {
        if (environment == null) {
            environment = context.getStringAttribute("default");
        }
        for (XNode child : context.getChildren()) {
            String id = child.getStringAttribute("id");
            //可以配置多个环境,判断是不是指定的环境
            if (isSpecifiedEnvironment(id)) {
                //获取事物管理器,创建事物管理器工厂
                TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
                //获取datasource工厂-UnpooledDataSourceFactory默认
                DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
                DataSource dataSource = dsFactory.getDataSource();
                Environment.Builder environmentBuilder = new Environment.Builder(id)
                    .transactionFactory(txFactory)
                    .dataSource(dataSource);
                configuration.setEnvironment(environmentBuilder.build());
            }
        }
    }
}

进入发现第一件是就是判断环境,没有指定就使用中default的环境id,在上面的XMLConfigBuilder的有参构造中this.environment = environment;将环境配置设置给了XMLConfigBuilder的environment 点我跳转到XMLConfigBuilder-有参构造

我们在使用时可以这样,在配置文件xml中,声明多个环境

主启动类中,手动指明一个配置环境

public static void main(String[] args) throws Exception {
    //....
    SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream,"myTest");
    //....
}

回到代码第一步就是判断用户选择的那个id的环境,之后创建事务管理器

XMLConfigBuilder.java

private void environmentsElement(XNode context) throws Exception {
    //..
    TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
    //..
}
private TransactionFactory transactionManagerElement(XNode context) throws Exception {
    if (context != null) {
        //获取我们在xml中声明的事务管理类型,当前是JDBC
        String type = context.getStringAttribute("type");
        //获取节点下的子节点,当前案例没有子节点
        Properties props = context.getChildrenAsProperties();
        //这里只是创建工厂类
        TransactionFactory factory = (TransactionFactory) resolveClass(type).newInstance();
        factory.setProperties(props);
        return factory;
    }
    throw new BuilderException("Environment declaration requires a TransactionFactory.");
}

这里调用resolveClass()方法是父类BaseBuilder的方法

一直点进去最后如下

TypeAliasRegistry.java

public class TypeAliasRegistry {
	 private final Map> TYPE_ALIASES = new HashMap>();
    //.....
    public  Class resolveAlias(String string) {
        try {
            if (string == null) {
                return null;
            }
            // issue #748
            String key = string.toLowerCase(Locale.ENGLISH);
            Class value;
            if (TYPE_ALIASES.containsKey(key)) {
                value = (Class) TYPE_ALIASES.get(key);
            } else {
                value = (Class) Resources.classForName(string);
            }
            return value;
        } catch (ClassNotFoundException e) {
            throw new TypeException("Could not resolve type alias '" + string + "'.  Cause: " + e, e);
        }
    }
}

判断这个TYPE_ALIASES map中是否存在JDBC这个key,如果不存在,则去加载

按理来说这里应该是不存在的,因为你在TypeAliasRegistry中找不到任何一个地方对TYPE_ALIASES添加一个JDBC的key

但是实际它却存在这个key,在Configuration类的无参构造时,对这个TypeAliasRegistry进行的添加

Configuration.java

 public Configuration() {
    typeAliasRegistry.registerAlias("JDBC", JdbcTransactionFactory.class);
     //...
    typeAliasRegistry.registerAlias("POOLED", PooledDataSourceFactory.class);
    languageRegistry.setDefaultDriverClass(XMLLanguageDriver.class);
	//......
  }

这个过程如下图

回到代码因为我们这次案例的配置为所以不会存在子节点context.getChildrenAsProperties();返回的结果0个配置项,transactionManagerElement方法结束

之后去解析数据库配置文件

XMLConfigBulider.java

private void environmentsElement(XNode context) throws Exception {
    //...
    //获取datasource工厂-UnpooledDataSourceFactory默认
    DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
    DataSource dataSource = dsFactory.getDataSource();
    //...
}

和解析环境基本一样的代码,不过解析dataSource的时候,子节点就不为空了

会有四个属性

  private DataSourceFactory dataSourceElement(XNode context) throws Exception {
    if (context != null) {
      String type = context.getStringAttribute("type");
      Properties props = context.getChildrenAsProperties();
       //type为POOLED的默认实现是PooledDataSourceFactory
      DataSourceFactory factory = (DataSourceFactory) resolveClass(type).newInstance();
      factory.setProperties(props);
      return factory;
    }
    throw new BuilderException("Environment declaration requires a DataSourceFactory.");
  }

进入factory.setProperties(props);

public class UnpooledDataSourceFactory implements DataSourceFactory {

    private static final String DRIVER_PROPERTY_PREFIX = "driver.";
    private static final int DRIVER_PROPERTY_PREFIX_LENGTH = DRIVER_PROPERTY_PREFIX.length();

    protected DataSource dataSource;
	//无参默认将dataSource设置为UnpooledDataSource
    public UnpooledDataSourceFactory() {
        this.dataSource = new UnpooledDataSource();
    }

    @Override
    public void setProperties(Properties properties) {
        Properties driverProperties = new Properties();
        //将工厂对象进行包装
        MetaObject metaDataSource = SystemMetaObject.forObject(dataSource);
        for (Object key : properties.keySet()) {
            String propertyName = (String) key;
            //如果存在driver
            if (propertyName.startsWith(DRIVER_PROPERTY_PREFIX)) {
                String value = properties.getProperty(propertyName);
                driverProperties.setProperty(propertyName.substring(DRIVER_PROPERTY_PREFIX_LENGTH), value);
            //如果当前属性在类中有对应的可以写入的属性
            } else if (metaDataSource.hasSetter(propertyName)) {
                String value = (String) properties.get(propertyName);
                Object convertedValue = convertValue(metaDataSource, propertyName, value);
                metaDataSource.setValue(propertyName, convertedValue);
            } else {
                throw new DataSourceException("Unknown DataSource property: " + propertyName);
            }
        }
        //如果属性不为空,则设置给meatDataSource
        if (driverProperties.size() > 0) {
            metaDataSource.setValue("driverProperties", driverProperties);
        }
    }
	//......
}

一顿设置后回到XMLConfigurationBuilder中的environmentsElement方法

最后将读取出的配置封装为Environment,赋值给BaseBuilder中的environment

private void environmentsElement(XNode context) throws Exception {
	//.....
    DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
    DataSource dataSource = dsFactory.getDataSource();
    Environment.Builder environmentBuilder = new Environment.Builder(id)
        .transactionFactory(txFactory)
        .dataSource(dataSource);
    configuration.setEnvironment(environmentBuilder.build());
	//.....
}

mapperElement

回到XMLConfigBuilder中的parseConfiguration

private void parseConfiguration(XNode root) {
    //.....
    //配置mapper
    mapperElement(root.evalNode("mappers"));

}

我们只看根据包扫描的,给Configuration中添加了mapper包名

private void mapperElement(XNode parent) throws Exception {
    if (parent != null) {
        for (XNode child : parent.getChildren()) {
            //使用包,默认查找指定包下位置
            if ("package".equals(child.getName())) {
                String mapperPackage = child.getStringAttribute("name");
                configuration.addMappers(mapperPackage);
            }
            //.....
        }
    }
}

Configuration.java

public void addMappers(String packageName) {
    mapperRegistry.addMappers(packageName);
}

MapperRegistry.java

public void addMappers(String packageName) {
    addMappers(packageName, Object.class);
}
//根据包名去查询该包下的类
public void addMappers(String packageName, Class> superType) {
    ResolverUtil> resolverUtil = new ResolverUtil>();
    resolverUtil.find(new ResolverUtil.IsA(superType), packageName);
    Set>> mapperSet = resolverUtil.getClasses();
    for (Class> mapperClass : mapperSet) {
        addMapper(mapperClass);
    }
}

之后就是动态代理对应的mapper
MapperRegistry.java

public  void addMapper(Class type) {
    if (type.isInterface()) {
        //判断是否已经存在
        if (hasMapper(type)) {
            throw new BindingException("Type " + type + " is already known to the MapperRegistry.");
        }
        boolean loadCompleted = false;
        try {
            knownMappers.put(type, new MapperProxyFactory(type));
            MapperAnnotationBuilder parser = new MapperAnnotationBuilder(config, type);
            parser.parse();
            loadCompleted = true;
        } finally {
            if (!loadCompleted) {
                knownMappers.remove(type);
            }
        }
    }
}

public class MapperProxyFactory {

    private final Class mapperInterface;
    private final Map methodCache = new ConcurrentHashMap();

    public MapperProxyFactory(Class mapperInterface) {
        this.mapperInterface = mapperInterface;
    }

    public Class getMapperInterface() {
        return mapperInterface;
    }

    public Map getMethodCache() {
        return methodCache;
    }

    @SuppressWarnings("unchecked")
    protected T newInstance(MapperProxy mapperProxy) {
        return (T) Proxy.newProxyInstance(mapperInterface.getClassLoader(), new Class[] { mapperInterface }, mapperProxy);
    }

    public T newInstance(SqlSession sqlSession) {
        final MapperProxy mapperProxy = new MapperProxy(sqlSession, mapperInterface, methodCache);
        return newInstance(mapperProxy);
    }

}

主要来看这段

MapperAnnotationBuilder parser = new MapperAnnotationBuilder(config, type);
parser.parse();

MapperAnnotationBuilder.java

public class MapperAnnotationBuilder {
    private final Set> sqlAnnotationTypes = new HashSet>();
    private final Set> sqlProviderAnnotationTypes = new HashSet>();
    //....
    /**
    * 在构造时添加mybatis的注解
    */
    public MapperAnnotationBuilder(Configuration configuration, Class> type) {
        String resource = type.getName().replace('.', '/') + ".java (best guess)";
        this.assistant = new MapperBuilderAssistant(configuration, resource);
        this.configuration = configuration;
        this.type = type;

        sqlAnnotationTypes.add(Select.class);
        sqlAnnotationTypes.add(Insert.class);
        sqlAnnotationTypes.add(Update.class);
        sqlAnnotationTypes.add(Delete.class);

        sqlProviderAnnotationTypes.add(SelectProvider.class);
        sqlProviderAnnotationTypes.add(InsertProvider.class);
        sqlProviderAnnotationTypes.add(UpdateProvider.class);
        sqlProviderAnnotationTypes.add(DeleteProvider.class);
    }


    public void parse() {
        String resource = type.toString();
        if (!configuration.isResourceLoaded(resource)) {
            loadXmlResource();
            configuration.addLoadedResource(resource);
            assistant.setCurrentNamespace(type.getName());
            parseCache();
            parseCacheRef();
            Method[] methods = type.getMethods();
            for (Method method : methods) {
                try {
                    // issue #237
                    if (!method.isBridge()) {
                        parseStatement(method);
                    }
                } catch (IncompleteElementException e) {
                    configuration.addIncompleteMethod(new MethodResolver(this, method));
                }
            }
        }
        parsePendingMethods();
    }
}

void parseStatement(Method method) {
    Class> parameterTypeClass = getParameterType(method);
    LanguageDriver languageDriver = getLanguageDriver(method);
    SqlSource sqlSource = getSqlSourceFromAnnotations(method, parameterTypeClass, languageDriver);
   //...
}

首先第一步是获取参数类型-代码如下,如果mapper的入参数量大于1,则返回的就是ParamMap.class

private Class> getParameterType(Method method) {
    Class> parameterType = null;
    Class>[] parameterTypes = method.getParameterTypes();
    for (int i = 0; i

之后获取语言解析,没有指定就去找默认-默认的是XMLLanguageDriver.class 还是在Configuration类无参构造时添加进去的点我跳转到Configuration-无参构造

private LanguageDriver getLanguageDriver(Method method) {
    Lang lang = method.getAnnotation(Lang.class);
    Class> langClass = null;
    if (lang != null) {
        langClass = lang.value();
    }
    return assistant.getLanguageDriver(langClass);
}

获取注解上的内容,以及封装sql就在这个方法

private SqlSource getSqlSourceFromAnnotations(Method method, Class> parameterType, LanguageDriver languageDriver) {
    try {
        //获取是否存在@Select,@Insert....
        Class extends Annotation> sqlAnnotationType = getSqlAnnotationType(method);
        //获取是否存在@SelectProvider,@InsertProvider...
        Class extends Annotation> sqlProviderAnnotationType = getSqlProviderAnnotationType(method);
        if (sqlAnnotationType != null) {
            if (sqlProviderAnnotationType != null) {
                throw new BindingException("You cannot supply both a static SQL and SqlProvider to method named " + method.getName());
            }
            Annotation sqlAnnotation = method.getAnnotation(sqlAnnotationType);
            //获取注解上的值
            final String[] strings = (String[]) sqlAnnotation.getClass().getMethod("value").invoke(sqlAnnotation);
            //返回sqlSource
            //这个时候还没有进行填充值
            return buildSqlSourceFromStrings(strings, parameterType, languageDriver);
        } else if (sqlProviderAnnotationType != null) {
            Annotation sqlProviderAnnotation = method.getAnnotation(sqlProviderAnnotationType);
            return new ProviderSqlSource(assistant.getConfiguration(), sqlProviderAnnotation);
        }
        return null;
    } catch (Exception e) {
        throw new BuilderException("Could not find value method on SQL annotation.  Cause: " + e, e);
    }
}

此时的strings值还是 select * from user where age = #{age} 需要给替换为 select * from user where age =?

  private SqlSource buildSqlSourceFromStrings(String[] strings, Class> parameterTypeClass, LanguageDriver languageDriver) {
    final StringBuilder sql = new StringBuilder();
    for (String fragment : strings) {
      sql.append(fragment);
      sql.append(" ");
    }
    return languageDriver.createSqlSource(configuration, sql.toString().trim(), parameterTypeClass);
  }

默认的语言驱动是XMLLanguageDriver

XMLLanguageDriver.java

首先判断注解上的内容是否存在脚本,在mybatis官网,动态SQL下的script有使用案例,使得在注解中可以像在xml中使用

@Override
public SqlSource createSqlSource(Configuration configuration, String script, Class> parameterType) {
    // issue #3
    if (script.startsWith("

之后在RewSqlSource中对sql进行解析

RewSqlSource.java

public RawSqlSource(Configuration configuration, String sql, Class> parameterType) {
    SqlSourceBuilder sqlSourceParser = new SqlSourceBuilder(configuration);
    Class> clazz = parameterType == null ? Object.class : parameterType;
    sqlSource = sqlSourceParser.parse(sql, clazz, new HashMap());
}

解析完最终结果如下

回到上个方法

  void parseStatement(Method method) {
    Class> parameterTypeClass = getParameterType(method);
    LanguageDriver languageDriver = getLanguageDriver(method);
    SqlSource sqlSource = getSqlSourceFromAnnotations(method, parameterTypeClass, languageDriver);
    //从这里继续
    if (sqlSource != null) {
      Options options = method.getAnnotation(Options.class);
      //mappedStatementId=类全限定+方法名
      final String mappedStatementId = type.getName() + "." + method.getName();
      //设置获取数据的大小
      Integer fetchSize = null;
      //设置此次查询超时时间
      Integer timeout = null;
      //https://blog.csdn.net/king101125s/article/details/104167493
      StatementType statementType = StatementType.PREPARED;
      //resultSet结果类型   FORWARD_ONLY 光标只能向前移动
      ResultSetType resultSetType = ResultSetType.FORWARD_ONLY;
      //设置sql类型,当前案例是SELECT
      SqlCommandType sqlCommandType = getSqlCommandType(method);
      boolean isSelect = sqlCommandType == SqlCommandType.SELECT;
      boolean flushCache = !isSelect;
      boolean useCache = isSelect;

      KeyGenerator keyGenerator;
      String keyProperty = "id";
      String keyColumn = null;
      if (SqlCommandType.INSERT.equals(sqlCommandType) || SqlCommandType.UPDATE.equals(sqlCommandType)) {
        // first check for SelectKey annotation - that overrides everything else
        SelectKey selectKey = method.getAnnotation(SelectKey.class);
        if (selectKey != null) {
          keyGenerator = handleSelectKeyAnnotation(selectKey, mappedStatementId, getParameterType(method), languageDriver);
          keyProperty = selectKey.keyProperty();
        } else if (options == null) {
          keyGenerator = configuration.isUseGeneratedKeys() ? new Jdbc3KeyGenerator() : new NoKeyGenerator();
        } else {
          keyGenerator = options.useGeneratedKeys() ? new Jdbc3KeyGenerator() : new NoKeyGenerator();
          keyProperty = options.keyProperty();
          keyColumn = options.keyColumn();
        }
      } else {
        keyGenerator = new NoKeyGenerator();
      }

      if (options != null) {
        flushCache = options.flushCache();
        useCache = options.useCache();
        fetchSize = options.fetchSize() > -1 || options.fetchSize() == Integer.MIN_VALUE ? options.fetchSize() : null; //issue #348
        timeout = options.timeout() > -1 ? options.timeout() : null;
        statementType = options.statementType();
        resultSetType = options.resultSetType();
      }

      String resultMapId = null;
      ResultMap resultMapAnnotation = method.getAnnotation(ResultMap.class);
      if (resultMapAnnotation != null) {
        String[] resultMaps = resultMapAnnotation.value();
        StringBuilder sb = new StringBuilder();
        for (String resultMap : resultMaps) {
          if (sb.length() > 0) {
            sb.append(",");
          }
          sb.append(resultMap);
        }
        resultMapId = sb.toString();
      } else if (isSelect) {
        resultMapId = parseResultMap(method);
      }
	//将参数传给小助手
      assistant.addMappedStatement(
          mappedStatementId,
          sqlSource,
          statementType,
          sqlCommandType,
          fetchSize,
          timeout,
          // ParameterMapID
          null,
          parameterTypeClass,
          resultMapId,
          getReturnType(method),
          resultSetType,
          flushCache,
          useCache,
          // TODO issue #577
          false,
          keyGenerator,
          keyProperty,
          keyColumn,
          // DatabaseID
          null,
          languageDriver,
          // ResultSets
          null);
    }
  }

添加mappedStatement

public MappedStatement addMappedStatement(
    String id,
    SqlSource sqlSource,
    StatementType statementType,
    SqlCommandType sqlCommandType,
    Integer fetchSize,
    Integer timeout,
    String parameterMap,
    Class> parameterType,
    String resultMap,
    Class> resultType,
    ResultSetType resultSetType,
    boolean flushCache,
    boolean useCache,
    boolean resultOrdered,
    KeyGenerator keyGenerator,
    String keyProperty,
    String keyColumn,
    String databaseId,
    LanguageDriver lang,
    String resultSets) {

    if (unresolvedCacheRef) {
        throw new IncompleteElementException("Cache-ref not yet resolved");
    }

    id = applyCurrentNamespace(id, false);
    boolean isSelect = sqlCommandType == SqlCommandType.SELECT;

    MappedStatement.Builder statementBuilder = new MappedStatement.Builder(configuration, id, sqlSource, sqlCommandType)
        .resource(resource)
        .fetchSize(fetchSize)
        .timeout(timeout)
        .statementType(statementType)
        .keyGenerator(keyGenerator)
        .keyProperty(keyProperty)
        .keyColumn(keyColumn)
        .databaseId(databaseId)
        .lang(lang)
        .resultOrdered(resultOrdered)
        .resulSets(resultSets)
        .resultMaps(getStatementResultMaps(resultMap, resultType, id))
        .resultSetType(resultSetType)
        .flushCacheRequired(valueOrDefault(flushCache, !isSelect))
        .useCache(valueOrDefault(useCache, isSelect))
        .cache(currentCache);

    ParameterMap statementParameterMap = getStatementParameterMap(parameterMap, parameterType, id);
    if (statementParameterMap != null) {
        statementBuilder.parameterMap(statementParameterMap);
    }

    MappedStatement statement = statementBuilder.build();
    //这里将这个MappedStatement放入configuration
    configuration.addMappedStatement(statement);
    return statement;
}

将各种参数最后封装为一个MappedStatement,放入configuration中,这样一个addMapper的方法就结束了

之后回到SqlSessionFactory的build中,执行重载的build

public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
    XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, environment, properties);
    //回到这里
    return build(parser.parse());

}
//默认为DefaultSqlSessionFactory
public SqlSessionFactory build(Configuration config) {
    return new DefaultSqlSessionFactory(config);
}

DefaultSqlSessionFactory.java

public class DefaultSqlSessionFactory implements SqlSessionFactory {

    private final Configuration configuration;

    public DefaultSqlSessionFactory(Configuration configuration) {
        this.configuration = configuration;
    }
    //.....
}

至此new SqlSessionFactoryBuilder().build(inputStream)这段代码的解析环境和加载mapper就分析完了

sqlSessionFactory

回到主代码

public static void main(String[] args) throws Exception {
    String resource = "org/mybatis/config.xml";
    InputStream inputStream = Resources.getResourceAsStream(resource);
    SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);
    SqlSession session = sqlSessionFactory.openSession();
    //..
}

开始分析sqlSessionFactory.openSession();

点进入发现有两个实现类,在上面的build中已经明确了创建的就是DefaultSqlSessionFactory

DefaultSqlSessionFactory.java

@Override
public SqlSession openSession() {
    //参数:执行器,默认为simple,每次关闭statement SimpleExecutor
    return openSessionFromDataSource(configuration.getDefaultExecutorType(), null, false);
}

configuration.getDefaultExecutorType()在Configuration类中获取的是本身的一个属性,类型是一个ExecutorType的枚举,默认为SIMPE

private SqlSession openSessionFromDataSource(ExecutorType execType, TransactionIsolationLevel level, boolean autoCommit) {
    Transaction tx = null;
    try {
        //获取配置类中的事务,datasource封装类
        final Environment environment = configuration.getEnvironment();
        //通过配置的环境中获取事务工厂
        final TransactionFactory transactionFactory = getTransactionFactoryFromEnvironment(environment);
        //创建对象/datasource/隔离等级/是否自动提交
        tx = transactionFactory.newTransaction(environment.getDataSource(), level, autoCommit);
        final Executor executor = configuration.newExecutor(tx, execType);
        return new DefaultSqlSession(configuration, executor, autoCommit);
    } catch (Exception e) {
        closeTransaction(tx); // may have fetched a connection so lets call close()
        throw ExceptionFactory.wrapException("Error opening session.  Cause: " + e, e);
    } finally {
        ErrorContext.instance().reset();
    }
}

获取configuration中的事务工厂之后创建一个执行器

Configuration.java

public Executor newExecutor(Transaction transaction, ExecutorType executorType) {
    executorType = executorType == null ? defaultExecutorType : executorType;
    executorType = executorType == null ? ExecutorType.SIMPLE : executorType;
    Executor executor;
    if (ExecutorType.BATCH == executorType) {
        executor = new BatchExecutor(this, transaction);
    } else if (ExecutorType.REUSE == executorType) {
        executor = new ReuseExecutor(this, transaction);
    } else {
        executor = new SimpleExecutor(this, transaction);
    }
    if (cacheEnabled) {
        executor = new CachingExecutor(executor);
    }
    executor = (Executor) interceptorChain.pluginAll(executor);
    return executor;
}

这里缓存是默认开启的,所以最后返回的是一个CachingExecutor 包含着一个SimpleExecutor

最后返回一个默认的DefaultSqlSession

DefaultSqlSession.java

    public DefaultSqlSession(Configuration configuration, Executor executor, boolean autoCommit) {
        this.configuration = configuration;
        this.executor = executor;
        this.dirty = false;
        this.autoCommit = autoCommit;
    }

到这里session也创建完成了之后就是获取mapper执行查询了

session.getMapper

DefaultSqlSession.java

@Override
public  T getMapper(Class type) {
    return configuration.getMapper(type, this);
}

Configuration.java

public  T getMapper(Class type, SqlSession sqlSession) {
    return mapperRegistry.getMapper(type, sqlSession);
}

MapperRegistry.java

public  T getMapper(Class type, SqlSession sqlSession) {
    final MapperProxyFactory mapperProxyFactory = (MapperProxyFactory) knownMappers.get(type);
    if (mapperProxyFactory == null) {
        throw new BindingException("Type " + type + " is not known to the MapperRegistry.");
    }
    try {
        return mapperProxyFactory.newInstance(sqlSession);
    } catch (Exception e) {
        throw new BindingException("Error getting mapper instance. Cause: " + e, e);
    }
}

MapperProxyFactory.java

protected T newInstance(MapperProxy mapperProxy) {
    return (T) Proxy.newProxyInstance(mapperInterface.getClassLoader(), new Class[] { mapperInterface }, mapperProxy);
}

public T newInstance(SqlSession sqlSession) {
    final MapperProxy mapperProxy = new MapperProxy(sqlSession, mapperInterface, methodCache);
    return newInstance(mapperProxy);
}

MapperProxy.java

动态代理来实现mapper的方法调用

public class MapperProxy implements InvocationHandler, Serializable {

    private static final long serialVersionUID = -6424540398559729838L;
    private final SqlSession sqlSession;
    private final Class mapperInterface;
    private final Map methodCache;

    public MapperProxy(SqlSession sqlSession, Class mapperInterface, Map methodCache) {
        this.sqlSession = sqlSession;
        this.mapperInterface = mapperInterface;
        this.methodCache = methodCache;
    }

    @Override
    public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
        if (Object.class.equals(method.getDeclaringClass())) {
            try {
                return method.invoke(this, args);
            } catch (Throwable t) {
                throw ExceptionUtil.unwrapThrowable(t);
            }
        }
        final MapperMethod mapperMethod = cachedMapperMethod(method);
        return mapperMethod.execute(sqlSession, args);
    }

    private MapperMethod cachedMapperMethod(Method method) {
        MapperMethod mapperMethod = methodCache.get(method);
        if (mapperMethod == null) {
            mapperMethod = new MapperMethod(mapperInterface, method, sqlSession.getConfiguration());
            methodCache.put(method, mapperMethod);
        }
        return mapperMethod;
    }

}

当我们执行userMapper.getUsers()的时候,通过动态代理进入invoke方法,之后获取缓存的方法,进入cachedMapperMethod

先找是否已经创建过这个方法的封装类了,如果没有则去创建

MapperMethod.java

 public MapperMethod(Class> mapperInterface, Method method, Configuration config) {
    thicnblogs.command = new SqlCommand(config, mapperInterface, method);
    this.method = new MethodSignature(config, method);
  }

MapperMethod.java-SqlCommand.java 静态内部类

public SqlCommand(Configuration configuration, Class> mapperInterface, Method method) {
    String statementName = mapperInterface.getName() + "." + method.getName();
    MappedStatement ms = null;
    //当程序走到这里的时候就会为true
    if (configuration.hasStatement(statementName)) {
        ms = configuration.getMappedStatement(statementName);
    }
    ///......
    if (ms == null) {
    //.....
    } else {
        name = ms.getId();
        type = ms.getSqlCommandType();
        if (type == SqlCommandType.UNKNOWN) {
            throw new BindingException("Unknown execution method for: " + name);
        }
    }
}

Configuration.java

public boolean hasStatement(String statementName) {
    return hasStatement(statementName, true);
}

public boolean hasStatement(String statementName, boolean validateIncompleteStatements) {
    if (validateIncompleteStatements) {
        buildAllStatements();
    }
    //主要这行
    return mappedStatements.containsKey(statementName);
}

可能忘了它什么时候添加进去的了,在那个小助手中的addMappedStatement方法,最后的时候进行的添加点我跳转到addMappedStatement

那么这里就直接走到最后的if了,将name和type赋值给SqlCommand,方法结束

之后还有创建MethodSignature

MapperMethod.java-MethodSignature.java 静态内部类

public MethodSignature(Configuration configuration, Method method) {
    this.returnType = method.getReturnType();
    this.returnsVoid = void.class.equals(this.returnType);
    this.returnsMany = (configuration.getObjectFactory().isCollection(this.returnType) || this.returnType.isArray());
    this.mapKey = getMapKey(method);
    this.returnsMap = (this.mapKey != null);
    //是否存在@Param注解
    this.hasNamedParameters = hasNamedParams(method);
    this.rowBoundsIndex = getUniqueParamIndex(method, RowBounds.class);
    this.resultHandlerIndex = getUniqueParamIndex(method, ResultHandler.class);
    this.params = Collections.unmodifiableSortedMap(getParams(method, this.hasNamedParameters));
}

走完这一系列后回到MapperProxy.java中的invoke方法,最后执行mapperMethod.execute(sqlSession, args)

MapperMethod.java

public Object execute(SqlSession sqlSession, Object[] args) {
    Object result;
    if(){
        //.......
    } else if (SqlCommandType.SELECT == command.getType()) {
        if (method.returnsVoid() && method.hasResultHandler()) {
            executeWithResultHandler(sqlSession, args);
            result = null;
        } else if (method.returnsMany()) {
            result = executeForMany(sqlSession, args);
        } else if (method.returnsMap()) {
            result = executeForMap(sqlSession, args);
        } else {
            Object param = method.convertArgsToSqlCommandParam(args);
            result = sqlSession.selectOne(command.getName(), param);
        }
    } else if (SqlCommandType.FLUSH == command.getType()) {
        result = sqlSession.flushStatements();
    } else {
        throw new BindingException("Unknown execution method for: " + command.getName());
    }
    if (result == null && method.getReturnType().isPrimitive() && !method.returnsVoid()) {
        throw new BindingException("Mapper method '" + command.getName()
                                   + " attempted to return null from a method with a primitive return type (" + method.getReturnType() + ").");
    }
    return result;
}

根据command的类型,当前这个案例是SELECT,进入后判断返回类型,当前是返回一个集合,returnsMany属性为ture,进入到result = executeForMany(sqlSession, args);

private  Object executeForMany(SqlSession sqlSession, Object[] args) {
    List result;
    //封装入参
    Object param = method.convertArgsToSqlCommandParam(args);
 	//这个为false,没有设置过逻辑分页
    if (method.hasRowBounds()) {
        RowBounds rowBounds = method.extractRowBounds(args);
        result = sqlSession.selectList(command.getName(), param, rowBounds);
    } else {
        result = sqlSession.selectList(command.getName(), param);
    }
    // issue #510 Collections & arrays support
    if (!method.getReturnType().isAssignableFrom(result.getClass())) {
        if (method.getReturnType().isArray()) {
            return convertToArray(result);
        } else {
            return convertToDeclaredCollection(sqlSession.getConfiguration(), result);
        }
    }
    return result;
}

public Object convertArgsToSqlCommandParam(Object[] args) {
    final int paramCount = params.size();
    if (args == null || paramCount == 0) {
        return null;
    } else if (!hasNamedParameters && paramCount == 1) {
        return args[params.keySet().iterator().next()];
    } else {
        final Map param = new ParamMap

封装mapper入参,没有入参返回null,一个入参返回数组,多个入参返回ParamMap

最终执行到result = sqlSession.selectList(command.getName(), param);

DefaultSqlSession.java

public  List selectList(String statement, Object parameter) {
    return this.selectList(statement, parameter, RowBounds.DEFAULT);
}

@Override
public  List selectList(String statement, Object parameter, RowBounds rowBounds) {
    try {
        MappedStatement ms = configuration.getMappedStatement(statement);
        return executor.query(ms, wrapCollection(parameter), rowBounds, Executor.NO_RESULT_HANDLER);
    } catch (Exception e) {
        throw ExceptionFactory.wrapException("Error querying database.  Cause: " + e, e);
    } finally {
        ErrorContext.instance().reset();
    }
}

warpCollection方法对入参同一封装了一遍

DefaultSqlSession.java

private Object wrapCollection(final Object object) {
    //如果是集合
    if (object instanceof Collection) {
        StrictMap

之后进入executor.query()

  @Override
  public  List query(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler) throws SQLException {
    BoundSql boundSql = ms.getBoundSql(parameter);
    CacheKey key = createCacheKey(ms, parameter, rowBounds, boundSql);
    return query(ms, parameter, rowBounds, resultHandler, key, boundSql);
 }

第一步先获取该方法对应的sql,入参类型,入参参数

ms.getBoundSql(parameter);

之后是创建缓存key

@Override
public CacheKey createCacheKey(MappedStatement ms, Object parameterObject, RowBounds rowBounds, BoundSql boundSql) {
    if (closed) {
        throw new ExecutorException("Executor was closed.");
    }
    CacheKey cacheKey = new CacheKey();
    cacheKey.update(ms.getId());
    cacheKey.update(Integer.valueOf(rowBounds.getOffset()));
    cacheKey.update(Integer.valueOf(rowBounds.getLimit()));
    cacheKey.update(boundSql.getSql());
    List parameterMappings = boundSql.getParameterMappings();
    TypeHandlerRegistry typeHandlerRegistry = ms.getConfiguration().getTypeHandlerRegistry();
    // mimic DefaultParameterHandler logic
    for (int i = 0; i

创建CacheKey作为缓存key的封装类,根据以下参数进行生成key

• MappedStatement的id
• rowBounds.getOffset() 跳过条数
• rowBounds.getLimit() 限制条数
• boundSql.getSql() 要执行的sql语句

之后遍历

如果是数组就将每个元素取出然后执行doUpdate,否则直接执行

CacheKey.java

private void doUpdate(Object object) {
    int baseHashCode = object == null ? 1 : object.hashCode();

    count++;
    checksum += baseHashCode;
    baseHashCode *= count;

    hashcode = multiplier * hashcode + baseHashCode;

    updateList.add(object);
}

最后走到query

CachingExecutor.java

@Override
public  List query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql)
    throws SQLException {
    Cache cache = ms.getCache();
    if (cache != null) {
        flushCacheIfRequired(ms);
        if (ms.isUseCache() && resultHandler == null) {
            ensureNoOutParams(ms, parameterObject, boundSql);
            @SuppressWarnings("unchecked")
            List list = (List) tcm.getObject(cache, key);
            if (list == null) {
                list = delegate. query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
                tcm.putObject(cache, key, list); // issue #578 and #116
            }
            return list;
        }
    }
    return delegate. query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
}

因为是首次进入,没有缓存,直接到BaseExecutor.query方法

BaseExecutor.java

@Override
public  List query(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
    ErrorContext.instance().resource(ms.getResource()).activity("executing a query").object(ms.getId());
    if (closed) {
        throw new ExecutorException("Executor was closed.");
    }
    if (queryStack == 0 && ms.isFlushCacheRequired()) {
        clearLocalCache();
    }
    List list;
    try {
        queryStack++;
        list = resultHandler == null ? (List) localCache.getObject(key) : null;
        if (list != null) {
            handleLocallyCachedOutputParameters(ms, key, parameter, boundSql);
        } else {
            list = queryFromDatabase(ms, parameter, rowBounds, resultHandler, key, boundSql);
        }
    } finally {
        queryStack--;
    }
    if (queryStack == 0) {
        for (DeferredLoad deferredLoad : deferredLoads) {
            deferredLoad.load();
        }
        // issue #601
        deferredLoads.clear();
        if (configuration.getLocalCacheScope() == LocalCacheScope.STATEMENT) {
            // issue #482
            clearLocalCache();
        }
    }
    return list;
}

进入后判断如果queryStack==0并且当前MappedStatement声明了需要清除缓存,则去清除缓存

@Options(flushCache= Options.FlushCachePolicy.TRUE)

将queryStack++,根据CacheKey获取对应缓存,如果没有则去查询数据库

queryStack的作用

BaseExecutor.java

private  List queryFromDatabase(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
    List list;
    localCache.putObject(key, EXECUTION_PLACEHOLDER);
    try {
        list = doQuery(ms, parameter, rowBounds, resultHandler, boundSql);
    } finally {
        localCache.removeObject(key);
    }
    localCache.putObject(key, list);
    if (ms.getStatementType() == StatementType.CALLABLE) {
        localOutputParameterCache.putObject(key, parameter);
    }
    return list;
}

进入doQuery

SimpleExecutor.java

@Override
public  List doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
    Statement stmt = null;
    try {
        Configuration configuration = ms.getConfiguration();
        StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
        stmt = prepareStatement(handler, ms.getStatementLog());
        return handler.query(stmt, resultHandler);
    } finally {
        closeStatement(stmt);
    }
}

创建statement执行类

public StatementHandler newStatementHandler(Executor executor, MappedStatement mappedStatement, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) {
    StatementHandler statementHandler = new RoutingStatementHandler(executor, mappedStatement, parameterObject, rowBounds, resultHandler, boundSql);
    statementHandler = (StatementHandler) interceptorChain.pluginAll(statementHandler);
    return statementHandler;
}

public RoutingStatementHandler(Executor executor, MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) {
    switch (ms.getStatementType()) {
        case STATEMENT:
            delegate = new SimpleStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
            break;
        case PREPARED:
            delegate = new PreparedStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
            break;
        case CALLABLE:
            delegate = new CallableStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
            break;
        default:
            throw new ExecutorException("Unknown statement type: " + ms.getStatementType());
    }
}

这里使用的是#{} MappedStatement的getStatementType返回为PREPARED 最后返回PreparedStatementHandler

之后解析prepareStatement

  private Statement prepareStatement(StatementHandler handler, Log statementLog) throws SQLException {
    Statement stmt;
    Connection connection = getConnection(statementLog);
    stmt = handler.prepare(connection);
    handler.parameterize(stmt);
    return stmt;
  }

获取连接之后解析statement

@Override
public Statement prepare(Connection connection) throws SQLException {
    Statement statement = null;
    statement = instantiateStatement(connection);
    //设置超时
    setStatementTimeout(statement);
    //设置获取数据大小
    setFetchSize(statement);
    return statement;
	//....
}

PreparedStatementHandler.java

@Override
protected Statement instantiateStatement(Connection connection) throws SQLException {
    String sql = boundSql.getSql();
    if (mappedStatement.getKeyGenerator() instanceof Jdbc3KeyGenerator) {
        String[] keyColumnNames = mappedStatement.getKeyColumns();
        if (keyColumnNames == null) {
            return connection.prepareStatement(sql, PreparedStatement.RETURN_GENERATED_KEYS);
        } else {
            return connection.prepareStatement(sql, keyColumnNames);
        }
    } else if (mappedStatement.getResultSetType() != null) {
        //将会走到这里返回preparedStatement
        return connection.prepareStatement(sql, mappedStatement.getResultSetType().getValue(), ResultSet.CONCUR_READ_ONLY);
    } else {
        return connection.prepareStatement(sql);
    }
}

之后执行handler.parameterize(stmt);

DefaultParameterHandler.java

@Override
public void setParameters(PreparedStatement ps) {
    ErrorContext.instance().activity("setting parameters").object(mappedStatement.getParameterMap().getId());
    List parameterMappings = boundSql.getParameterMappings();
    if (parameterMappings != null) {
        for (int i = 0; i

BaseTypeHandler.java

@Override
public void setParameter(PreparedStatement ps, int i, T parameter, JdbcType jdbcType) throws SQLException {
    if (parameter == null) {
        if (jdbcType == null) {
            throw new TypeException("JDBC requires that the JdbcType must be specified for all nullable parameters.");
        }
        try {
            ps.setNull(i, jdbcType.TYPE_CODE);
        } catch (SQLException e) {
            throw new TypeException("Error setting null for parameter #" + i + " with JdbcType " + jdbcType + " . " +
                                    "Try setting a different JdbcType for this parameter or a different jdbcTypeForNull configuration property. " +
                                    "Cause: " + e, e);
        }
    } else {
        try {
            //进入这里
            setNonNullParameter(ps, i, parameter, jdbcType);
        } catch (Exception e) {
            throw new TypeException("Error setting non null for parameter #" + i + " with JdbcType " + jdbcType + " . " +
                                    "Try setting a different JdbcType for this parameter or a different configuration property. " +
                                    "Cause: " + e, e);
        }
    }
}

public class IntegerTypeHandler extends BaseTypeHandler {
    @Override
    public void setNonNullParameter(PreparedStatement ps, int i, Integer parameter, JdbcType jdbcType)
        throws SQLException {
        ps.setInt(i, parameter);
    }
}

最后回到SimpleExecutor类中的prepareStatement方法,返回PreparedStatement

@Override
public  List doQuery(MappedStatement ms, Object param
