mosquitto简述

概述

mosquitto是一款开源的MQTT消息代理（服务器）软件，实现了MQTT协议版本3.1和3.1.1，提供轻量级的，支持可发布/可订阅的的消息推送模式。

官网：Eclipse Mosquitto

API：mosquitto.h

安装

sudo apt install mosquitto  # 安装服务端
sudo apt install mosquitto-clients  # 安装客户端
sudo apt-get install libmosquitto-dev # C风格开发依赖包
sudo apt-get install libmosquittopp-dev  # C++风格封装的libmosquitto开发包

服务端指令

  • 查看服务状态

    sudo service mosquitto status

  • 启动服务器

    sudo service mosquitto start

  • 关闭服务器

    sudo service mosquitto stop

  • 启动服务器并实时显示所有日志

    mosquitto -v

  • 根据指定的配置文件启动服务器

    mosquitto -c /etc/mosquitto/mosquitto.conf -d
    • ​-c : 指定配置文件
    • ​-d : 后台运行

  • 指定端口启动服务器，默认端口是1883，最多指定10次

    mosquitto -p 1884

配置文件

​/etc/mosquitto/mosquitto.conf​

# 消息持久存储
persistence true
persistence_location /var/lib/mosquitto/

日志文件


log_dest file /var/log/mosquitto/mosquitto.log


其他配置


include_dir /etc/mosquitto/conf.d


禁止匿名访问


allow_anonymous false


认证配置，即登录账号信息的文件


password_file /etc/mosquitto/pwfile


权限配置


acl_file /etc/mosquitto/aclfile


监听的端口


listener 1883

客户端指令

订阅主题

mosquitto_sub -t topic

发布主题

mosquitto_pub -t topic -m '消息'

Mosquitto库编程（C风格）

发布信息客户端

​mqtt_pub.c​

#include
#include
#include
#include

define HOST "127.0.0.1"


define PORT  1883


define KEEP_ALIVE_TIME 60


define MSG_MAX_SIZE  512


bool session = true;


int main(void)

{

int err = 0;

printf("mqtt publish init ...n");

struct mosquitto* mosq = NULL;

char buff[MSG_MAX_SIZE];


// 初始化
err = mosquitto_lib_init();
if(err<0)
{
    printf("mosquitto lib int fail...");
    return -1;
}

// 创建客户端
mosq = mosquitto_new(NULL, session, NULL);
if(mosq==NULL)
{
    printf("create client failed...n");
    err = -1;
    mosquitto_lib_cleanup();
    return -1;
}

// 客户端连接broker
err = mosquitto_connect(mosq, HOST, PORT, KEEP_ALIVE_TIME);
if(err<0)
{
    printf("connect fail");
    mosquitto_destroy(mosq);
    return -1;
}

// 启动事件循环（启动独立线程处理mosquitto事件）
err = mosquitto_loop_start(mosq);
if(err!=MOSQ_ERR_SUCCESS)
{
    printf("mosquitto loop errorn");
    mosquitto_disconnect(mosq);
    return -1;
}

// 发布信息到test主题
strncpy(buff, "hello world!", 13);
mosquitto_publish(mosq, NULL, "test", strlen(buff)+1, buff, 0, 0);

mosquitto_disconnect(mosq);
mosquitto_loop_stop(mosq, true);
mosquitto_destroy(mosq);
mosquitto_lib_cleanup();

return 0;



}

订阅信息客户端

​mqtt_sub.c​

#include
#include
#include
#include

define HOST "127.0.0.1"


define PORT  1883


define KEEP_ALIVE 60


bool session = true;


// 订阅主题成功时回调

void mqtt_subscribe_callback(struct mosquitto *mosq,

void *userdata, int mid, int qos_count, const int *granted_qos)

{

int i;

printf("subscribed (mid: %d): %d", mid, granted_qos[0]);

for(i=1; i
printf(", %d", granted_qos[i]);

}

printf("n");

}


//消息回调函数，收到订阅的消息后调用

void mqtt_message_callback(struct mosquitto *mosq, void *userdata, const struct mosquitto_message *message)

{

if (message->payloadlen){

printf("%s: %s n", message->topic, (char *)message->payload);

}else{

printf("%s (null)n",message->topic);

}

}


//mqtt连接回调

void mqtt_connect_callback(struct mosquitto *mosq, void *userdata, int result)

{

int ret;

if (!result){

ret = mosquitto_subscribe(mosq, NULL, "test", 2);

if(ret
printf("Subscription failedn");

}else{

printf("Subscription succeededn");

}

}else{

printf("connect failedn");

}

}


//日志回调函数

void mqtt_log_callback(struct mosquitto *mosq, void *userdata, int level, const char *str)

{

printf("log__   %sn", str);

}


int main(void)

{


int err = 0;
printf("mqtt client init...n");

struct mosquitto *mosq = NULL;

//libmosquitto 库初始化
err = mosquitto_lib_init();
if (err < 0){
    printf("mosquitto lib int fail...");
    return err;
}

//创建mosquitto客户端
mosq = mosquitto_new(NULL,session,NULL);
if (mosq == NULL){
    printf("create client failed...n");
    err = -1;
    mosquitto_lib_cleanup();
    return err;
}

//设置回调函数
mosquitto_log_callback_set(mosq, mqtt_log_callback);
mosquitto_connect_callback_set(mosq, mqtt_connect_callback);
mosquitto_message_callback_set(mosq, mqtt_message_callback);
mosquitto_subscribe_callback_set(mosq, mqtt_subscribe_callback);

//客户端连接服务器
err = mosquitto_connect(mosq, HOST, PORT, KEEP_ALIVE);
if (err < 0){
    printf("connect fail");
    mosquitto_destroy(mosq);
    return err;
}

//启动事件循环，永久阻塞
err = mosquitto_loop_forever(mosq, -1, 1);
if (err < 0){
    printf("mosquitto loop fail");
    mosquitto_disconnect(mosq);
    return err;
}

mosquitto_disconnect(mosq);
mosquitto_loop_stop(mosq, false);
mosquitto_destroy(mosq);
mosquitto_lib_cleanup();

return 0;



}

编译

​CMakeLists.txt​

cmake_minimum_required(VERSION 3.16)

project(mosquitto_demo)


find_package(PkgConfig REQUIRED)


pkg_check_modules(MOSQ libmosquitto)


set(PUB_SOURCES mqtt_pub.c)

set(SUB_SOURCES mqtt_sub.c)


add_executable(subclient ${SUB_SOURCES})

add_executable(pubclient ${PUB_SOURCES})


target_include_directories(subclient PRIVATE ${MOSQ_INCLUDE_DIRS})

target_link_libraries(subclient PRIVATE ${MOSQ_LIBRARIES})


target_include_directories(pubclient PRIVATE ${MOSQ_INCLUDE_DIRS})

target_link_libraries(pubclient PRIVATE ${MOSQ_LIBRARIES})

Mosquittopp库编程（C++风格）

订阅信息客户端

​subclient.cc​

#include
#include
#include

const char* topic = "topic1";

const char* host = "127.0.0.1";

const int port = 1883;

const int alivetime = 60;


class MqttSubClient:public mosqpp::mosquittopp

{

public:

MqttSubClient(const char* id):mosquittopp(id){}

void on_connect(int rc) override;

void on_disconnect(int rc) override;

void on_subscribe(int mid, int qos_count, const int* granted_qos) override;

void on_message(const struct mosquitto_message* message) override;

};


// 连接回调函数

void MqttSubClient::on_connect(int rc)

{

if(rc == MOSQ_ERR_SUCCESS)

{

std::cout
// 订阅主题

subscribe(nullptr, topic, 1);

}

else

{

std::cerr
}

}


// 断开连接回调函数

void MqttSubClient::on_disconnect(int rc)

{

std::cout
}


// 订阅成功回调函数

void MqttSubClient::on_subscribe(int mid, int qos_count, const int* granted_qos)

{

std::cout
}


// 消息处理回调函数

void MqttSubClient::on_message(const struct mosquitto_message* message)

{

bool match = false;

mosqpp::topic_matches_sub(topic, message->topic, &match);

if(match)

{

std::string recv(static_cast(message->payload), message->payloadlen);

std::couttopicmid
}

}


int main()

{

// 初始化

mosqpp::lib_init();

MqttSubClient subclient("subclient1");

int rc;

rc = subclient.connect(host, port, alivetime);

if(rc == MOSQ_ERR_ERRNO)

{

std::cout
}

else if(MOSQ_ERR_SUCCESS == rc)

{

// 启动事件循环，并阻塞

rc = subclient.loop_forever();

}


subclient.disconnect();
mosqpp::lib_cleanup();


return 0;



}

发布信息客户端

​pubclient.cc​

#include
#include
#include
#include

const char* topic = "topic1";

const char* host = "127.0.0.1";

const int port = 1883;

const int alivetime = 60;


class MqttPubClient:public mosqpp::mosquittopp

{

public:

MqttPubClient(const char* id):mosquittopp(id){}

/// @brief 连接broker时回调

/// @param rc 返回码

void on_connect(int rc) override;

/// @brief 断开连接时回调

/// @param rc 返回码

void on_disconnect(int rc) override;

/// @brief 消息发布成功时回调

/// @param mid

void on_publish(int mid) override;

/// @brief 发布消息

/// @param message 要发布的消息

/// @param qos 定义消息传输可靠性 0 1 2

void publish_message(std::string message, int qos);

};


void MqttPubClient::on_connect(int rc)

{

if(rc == MOSQ_ERR_SUCCESS)

{

std::cout
}

else

{

std::cout
}

}


void MqttPubClient::on_disconnect(int rc)

{

std::cout
}


void MqttPubClient::on_publish(int mid)

{

std::cout
}


void MqttPubClient::publish_message(std::string message, int qos)

{

int ret = publish(nullptr, topic, message.size(), message.c_str(), qos, false);

if(ret != MOSQ_ERR_SUCCESS)

{

std::cerr
}

}


int main()

{

// 初始化

mosqpp::lib_init();

MqttPubClient publisher("cpp_publisher");


int rc = publisher.connect(host, port, alivetime);
if(rc != MOSQ_ERR_SUCCESS)
{
    std::cerr<<"connect error!"<<mosqpp::strerror(rc)<<std::endl;
    return -1;
}

// 启动异步事件循环
publisher.loop_start();

// 消息发布
std::string msg;
std::this_thread::sleep_for(std::chrono::milliseconds(5));  // 两个sleep是为了确保主线程的输出在后台线程的回调函数输出之后
std::cout<<"请输入要发布的消息：";
while(std::cin>>msg)
{
    publisher.publish_message(msg, 1);
    std::this_thread::sleep_for(std::chrono::milliseconds(5));
    std::cout<<"请输入要发布的消息：";
}

// 清理资源
publisher.loop_stop(true);
publisher.disconnect();
mosqpp::lib_cleanup();

return 0;



}

编译

​CMakeLists.txt​

cmake_minimum_required(VERSION 3.16)

project(mqtt_cpp_style)


find_package(PkgConfig REQUIRED)


pkg_check_modules(MOSQ libmosquittopp)


set(SUBSRC subclient.cc)

set(PUBSRC pubclient.cc)


add_executable(subclient ${SUBSRC})

add_executable(pubclient ${PUBSRC})


target_include_directories(subclient PRIVATE ${MOSQ_INCLUDE_DIRS})

target_link_libraries(subclient PRIVATE ${MOSQ_LIBRARIES})


target_include_directories(pubclient PRIVATE ${MOSQ_INCLUDE_DIRS})

target_link_libraries(pubclient PRIVATE ${MOSQ_LIBRARIES})

‍
